Westgate Black Small LED Flood Light with Photocell Power and CCT Adjustable 10W/20W/30W, 120-277V, 3000K/4000K/5000K/5700K - LFX-SM-10-30W-MCTP-KN-BK-P

Key Specification

• Input Voltage: 120-277VAC, 50/60Hz
• Power: 10W/20W/30W (Selectable)
• Efficacy: 130 LM/W
• Lumen Output: 1,300LM / 2,600LM / 3,900LM
• CCT: 3000K/4000K/5000K/5700K (Selectable)
• CRI: ≥82
• Dimming: 0-10V Dimming
• Photocell: Pre-installed DC Button Photocell
• Housing: Die-Cast Aluminum with Powder-Coat Finish
• Finish: Black
• Mounting: 90° Adjustable 1/2" Knuckle Mount
• Optic: Type III
• Beam Angle: 120° × 90°
• IP Rating: IP65, Wet Location Rated
• Operating Temperature: -40°F to 122°F
• Rated Life: 70,000 Hours
• Certifications: DLC Premium, UL Listed
• BUG Rating: B2-U0-G1
• Warranty: 7 Years

The Westgate Black Small LED Flood Light with Photocell is a versatile and efficient outdoor lighting solution designed to provide reliable illumination for residential, commercial and industrial applications. Featuring selectable power levels of 10W, 20W and 30W, four selectable colour temperatures — 3000K, 4000K, 5000K and 5700K — and integrated photocell functionality, this flood light offers flexible performance for a variety of outdoor lighting requirements.

Its compact design and black finish provide a clean, professional appearance, while the adjustable power and colour temperature settings allow the fixture to be configured according to the application's lighting needs.

Ideal Applications

• Building façades
• Parking areas
• Walkways and pathways
• Entrances
• Security lighting
• Commercial properties
• Warehouses
• Industrial facilities
• Loading areas
• Outdoor recreational areas
• Landscape and architectural lighting
• General area lighting

What's Included / Features

The Westgate LFX-SM-10-30W-MCTP-KN-BK-P combines a compact LED flood light design with power-adjustable, multi-CCT and photocell functionality. The selectable 10W/20W/30W power levels allow users to adjust the light output to suit different mounting heights, coverage areas and illumination requirements.

The selectable 3000K/4000K/5000K/5700K colour temperatures provide four lighting options, ranging from warm illumination to cool daylight-style light. This makes the fixture suitable for a wide variety of exterior applications.

The integrated photocell enables automatic operation based on ambient light conditions, making it suitable for applications requiring automatic dusk-to-dawn lighting. Its broad 120–277V AC input range provides installation flexibility across commercial and industrial electrical systems.

The black finish provides a modern and professional appearance that complements a wide range of exterior environments.

Key Features:

• Product Type: LED Flood Light
• Model: LFX-SM-10-30W-MCTP-KN-BK-P
• Size: Small
• Selectable Wattage: 10W / 20W / 30W
• Input Voltage: 120–277V AC
• Selectable Colour Temperature: 3000K / 4000K / 5000K / 5700K
• Multi-Power: Yes
• Multi-CCT: Yes
• Photocell: Integrated
• Finish: Black
• Outdoor Flood Light Design
• Power-Adjustable Configuration
• Flexible Colour Temperature Selection
• Automatic Photocell Operation
• Energy-Efficient LED Technology
• Broad Area Illumination
• Wide Voltage Compatibility
• Compact Design
• Modern Appearance
• Low-Maintenance Operation
• Suitable for Residential, Commercial and Industrial Applications
• Ideal for: Building façades, parking areas, walkways, entrances, security lighting, warehouses, loading areas, industrial facilities, recreational areas, landscape lighting and general outdoor illumination
