LED Driver T8 LED Electronic Parallel 16W, 120-277V, 50/60 Hz - ICN2P16TLEDN35M

Key Specification

• Product Type: T8 LED Lamp
• Brand: Philips LED InstantFit / Centium (driver compatibility)
• Driver Type: T8 LED Electronic
• Lamp Connection: Parallel
• Input Voltage: 120–277 V
• Input Frequency: 50/60 Hz
• Compatible Lamp Types:
  • T8 LED 2 ft, 3 ft, 4 ft
  • U-bent T8 (6U)
  • Standard & High Output (HO/UHO variants)
• Lamp Wattage Range: 8.5 W – 16.5 W
• Lumens Output Range: 950 – 2500 lm
• Number of Lamps: 1–2
• Input Power Range: 12 – 40 W
• Input Current Range: 0.05 – 0.33 A
• Power Factor: 0.88 – 0.99
• Total Harmonic Distortion (THD): 10 – 15%
• Minimum Start Temperature: -13°F (-25°C)
• Status: Active

The LED Driver T8 Electronic Parallel – 16W, 120–277V is a high-quality and efficient driver designed for T8 LED tube lighting systems. It delivers stable and consistent performance using electronic parallel technology, making it ideal for both retrofit and new installations. With support for 50/60 Hz input, it ensures reliable operation across a wide range of electrical environments. Its durable and compact design allows easy integration into various lighting fixtures.

Common Applications:

• T8 LED tube retrofits in offices and commercial buildings
• Retail lighting in supermarkets and shopping centers
• Educational institutions and hospitals
• Warehouses and industrial lighting systems
• General indoor lighting upgrades for improved energy efficiency

Key Features:

• Wide input voltage range: 120–277V
• Power rating: 16W for efficient LED tube operation
• Electronic parallel configuration for stable performance
• Compatible with 50/60 Hz power systems
• Compact and lightweight design for easy installation
• Reliable and long-life operation for commercial use
