LED Driver 12W, Electronic Dimming Parallel, 120-277V, 50/60 Hz - IZT2P16TLEDSC35M

Key Specification

• Brand Name: Mark 7 0-10V
• Driver Type: Electronic Dimming
• Lamp Connection: Parallel
• Input Voltage: 120–277V
• Input Frequency: 50/60 Hz
• Status: Active
• Performance (varies by model):
  • Bare Lamp Wattage: 8.9W to 12W range (depending on variant)
  • Nominal Initial Lumens: 1500 to 1800 lm
  • Minimum Start Temperature: -13°F to -25°F
  • Number of Lamps Supported: 1 to 2 lamps (depending on configuration)
• Electrical Performance:
  • Input Current (Max Output): approx. 0.14A – 0.28A range
  • Input Power: varies by model (approx. 3W to 34W range shown per configuration)
  • Total Harmonic Distortion (THD): 10%
  • Power Factor: 0.98 – 0.99 (at max output)

The LED Driver 12W Electronic Dimming Parallel – 120–277V is a compact and efficient solution designed for LED tube lighting applications. It offers stable and reliable performance with electronic parallel operation, ensuring consistent illumination in both retrofit and new installations. With integrated dimming capability, it allows flexible control of light levels. Its durable construction ensures long-lasting and dependable operation.

Common Applications:

• LED tube retrofits in offices and commercial spaces
• Retail lighting in stores and supermarkets
• Educational institutions and training facilities
• Healthcare environments such as hospitals and clinics
• General indoor lighting upgrades with dimming requirements

Key Features:

• Wide input voltage range: 120–277V
• Power rating: 12W for energy-efficient operation
• Electronic parallel design for stable LED performance
• Integrated dimming functionality for adjustable brightness
• Compatible with 50/60 Hz electrical systems
• Compact and durable design for easy installation
